Set Up an IPv6 Tunnel on Your Linode

As IPv4 address exhaustion nears, many people are making the switch to IPv6. Linode offers native IPv6 addresses in all locations.

An IPv6 tunnel lets a system reach an IPv6 network using existing IPv4 connectivity. Follow this guide if you:

• Have a tunnel that you are migrating to your Linode.

• Don’t have IPv6 from your ISP, and want to interact with your Linode through its IPv6 address. By configuring the tunnel to a local computer instead of your Linode, you can connect to your Linode via the IPv6 address.

Before You Begin

You should have already signed up for an IPv6 tunnel through a tunnel broker. Wikipedia contains a list of tunnel brokers by region, and we encourage you to research each before you decide which to use. The steps outlined in this guide were performed using tunnels from Hurricane Electric (HE).

General Setup

Once you have signed up for a tunnel, you will need to issue a few commands on your Linode. Arch and Gentoo Linux users may need to install the iproute2 package before continuing.

1. Because some of these steps will temporarily disable networking on the Linode, begin by logging in using either the Lish or Glish interface.

2. Use the ip tool to add the tunnel device. Ours is called he-ipv6 to match the device described in Hurricane Electric’s examples. Replace 203.0.113.10 with the endpoint of your tunnel, and 198.51.100.5 with your Linode’s IP address. The information for the endpoint can be found in your tunnel broker’s web interface, and your Linode’s IP address can be found under the Networking tab of the Linode Cloud Manager:

   ip tunnel add he-ipv6 mode sit remote 203.0.113.10 local 198.51.100.5 ttl 255
   ip link set he-ipv6 up


   For more information on how the ip tool configures tunnels, see the ip-tunnel documentation.

3. Assign IPv6 address and routing information to your new tunnel device. Replace 2001:db8:1234:5678::2/64 with the IPv6 address assigned to you. This information should be provided to you by your tunnel broker as your “Client IPv6 Address”:

   Important

   The ifdown command will halt all network traffic to your Linode. This step is included to avoid an error when adding the IPv6 route. It may not be required on all Linux distributions.

   On Arch Linux, replace the ifdown and ifup commands with ip link set eth0 down and ip link set eth0 up

   ip addr add 2001:db8:1234:5678::2/64 dev he-ipv6
   ifdown eth0
   ip route add ::/0 dev he-ipv6
   ifup eth0
   ip -f inet6 addr


   The final command in Line 5 will show all devices with IPv6 addresses, and should have a block similar to this:

   13: he-ipv6@NONE: <POINTOPOINT,NOARP,UP,LOWER_UP> mtu 1480 state UNKNOWN qlen 1
       inet6 2001:db8:1234:5678::2/64 scope global
          valid_lft forever preferred_lft forever
       inet6 fe80::0000:0000/64 scope link
          valid_lft forever preferred_lft forever


4. Test the tunnel. Replace he-ipv6 with the name of your tunnel. On Arch Linux and other distributions without ping6, use ping -6 instead.

   ping6 -I he-ipv6 irc6.oftc.net


   Note

   Your system must allow ICMPv6 in through the firewall for pings to be returned.

If everything is working, you should see ping replies. If not, go back and make sure that you haven’t made any errors.

Manual Configuration

The instructions in this section will allow you to manually configure your IPv6 tunnel. This can permanently affect your connectivity across reboots. Read the IPv6 documentation for your distribution before proceeding.

Debian and Ubuntu

Debian and Ubuntu users (versions before Ubuntu 16.04 are not covered here) can perform the following steps to set up a tunnel on their Linode.

1. In the following excerpt, replace the:

   • address value with the “Client IPv6 address.”
   • gateway value with the “Server IPv6 address.”
   • endpoint value with the endpoint, or “Server IPv4 Address,” that your tunnel broker provides you. Generally this endpoint is in a geographical location that is close to your Linode.
   • local value with your Linode’s IP address. If you have multiple IPs, make sure that this IP is set to the same address as the one you used to sign up for the tunnel.

   Insert the following into your /etc/network/interfaces file:

   File: /etc/network/interfaces

   1 2 3 4 5 6 7 8

   auto he-ipv6 iface he-ipv6 inet6 v4tunnel address 2001:db8:1234:5678::2 netmask 64 endpoint 203.0.113.10 local 198.51.100.5 ttl 255 gateway 2001:db8:1234:5678::1

2. Restart networking services and test the tunnel. Replace he-ipv6 with the name of your tunnel:

   systemctl restart networking.service
   ping6 -I he-ipv6 irc6.oftc.net


   If configuration was successful, you will receive ping replies. If not, check your network configuration for errors.

CentOS 7 and Fedora 22+

1. Create a file at /etc/sysconfig/network-scripts/ifcfg-he-ipv6 that contains the following:

   File: /etc/sysconfig/network-scripts/ifcfg-he-ipv6

   1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24

   NAME="he-ipv6" DEVICE=he-ipv6 ONBOOT=yes USERCTL=yes BOOTPROTO=none PEERDNS=no IPV6INIT=yes IPV6_AUTOTUNNEL=yes IPV6ADDR="2001:db8:1234:5678::2/64" IPV6_ROUTER=yes IPV6_AUTOCONF=no IPV6_CONTROL_RADVD=yes IPV6TUNNELIPV4=203.0.113.10 IPV6TUNNELIPV4LOCAL=45.79.171.199 PHYSDEV=eth0 TYPE=sit DEVICETYPE=sit NM_CONTROLLED=no IPV6_DEFAULTGW=2001:db8:1234:5678::1 IPV6_DEFAULTDEV=he-ipv6

   In the above, replace the:

   • IPV6ADDR value with your “Client IPV6 Address.”
   • IPV6TUNNELIPV4 value with your “Server IPV4 Address.”
   • IPV6TUNNELIPV4LOCAL value with your “Client IPV4 Address.”
   • IPV6_DEFAULTGW value with your “Server IPV6 Address.”

2. Start the he-ipv6 interface:

   ifup he-ipv6


3. Test the tunnel. Replace he-ipv6 with the name of your tunnel:

   ping6 -I he-ipv6 irc6.oftc.net


   If configuration was successful, you will receive ping replies. If not, check your network configuration for errors.

CentOS 6

1. Add the following lines to your /etc/sysconfig/network file:

   File: /etc/sysconfig/network

   1 2	NETWORKING_IPV6=yes IPV6_DEFAULTDEV=he-ipv6

2. Create a file at /etc/sysconfig/network-scripts/ifcfg-he-ipv6 that contains the following:

   File: /etc/sysconfig/network-scripts/ifcfg-he-ipv6

   1 2 3 4 5 6

   DEVICE=he-ipv6 BOOTPROTO=none ONBOOT=yes IPV6INIT=yes IPV6TUNNELIPV4=203.0.113.10 IPV6ADDR=2001:db8:1234:5678::2/64

   Replace the IPV6TUNNELIPV4 value with your remote tunnel endpoint and the IPV6ADDR value with the “Client IPv6” address provided to you by your tunnel broker.

3. Start the he-ipv6 interface:

   ifup he-ipv6


4. Test the tunnel. Replace he-ipv6 with the name of your tunnel:

   ping6 -I he-ipv6 irc6.oftc.net


   If configuration was successful, you will receive ping replies. If not, check your network configuration for errors.

Arch Linux

Refer to the Arch Linux Wiki for more information.

Gentoo Linux

Refer to the Gentoo Linux Wiki for more information.
